VariAx 2 Design (In progress not done yet) Volar Distal Radius Plate Tapered distal portion designed to reduce the risk of protrusion and soft tissue irritation K-wire holes to assess screw trajectories Functional window for fracture visualization, bone grafting insertion, and additional locking screw fixation Transverse oblong hole designed to allow for ulnar/radial adjustment Extended Volar Distal Radius Plate Tapered distal portion designed to reduce the risk of protrusion and soft tissue irritation around the watershed line Low profile pre-bent extension designed for buttressing of fractures involving the volar ulnar corner Suture holes designed to allow for volar capsule tissue approximation with sutures XXS Distal Radius Plate Designed for a minimally invasive approach Available sterile only Technical specifications Nail diameter Ø9mm – Ø15mm Nail length 240mm – 480mm in 20mm increments Locking Screw Ø5mm, 25mm – 120mm length 25mm - 60mm in 2.5mm increments 60mm - 120mm in 5mm increments Advanced Locking Screws Ø5mm, 30mm – 100mm length 30mm - 60mm in 2.5mm increments 60mm - 100mm in 5mm increments .T2 Lag Screws Recon Ø6.5mm, 65mm – 130mm length Screws Femur Antegrade GT/PF Nailing System Femur Antegrade GT/PF Nailing System Locking Screws Ø5mm, 25mm – 120mm length 25mm - 60mm in 2.5mm increments 60mm - 120mm in 5mm increments Advanced Locking Screws Ø5mm, 30mm – 100mm length 30mm - 60mm in 2.5mm increments 60mm - 100mm in 5mm increments T2 Lag Screws Recon Ø6.5mm, 65mm – 130mm length
